CHME series horizontal intelligent constant pressure frequency conversion pump adopts the technology of frequency conversion speed regulation and automatic control, together with the high-efficiency and energy-saving CHM non-self-priming light horizontal multistage centrifugal pump.

The whole machine is mainly composed of CHM pump, controller, sensor, pressure tank, check valve and axial seismic pressure gauge.

It has the characteristics of stable performance, high efficiency and energy saving, automatic intelligent control, low noise, corrosion resistance, compact structure, beautiful appearance, small size, light weight and so on.



Fully automatic operation:  It can start and stop automatically according to demand, and can automatically adjust speed according to the water amount to ensure constant pressure and energy saving.

Clean and sanitary:  The flow parts are all made of stainless steel to ensure that the water quality will not be contaminated again.

Constant pressure:  Keep constant pipeline pressure through Differential Compensation Principle of pressure tank.

Electrical protection: The controller has protection against overcurrent, overload, and lack-phase. When the controller detects an electrical fault, an inverter fault signal will appear on the display screen and the pump will be automatically shut down to protect it.

Self-set pressure: The pressure can be set by the control panel within the pump performance range.

High efficiency and energy saving: When the user's water consumption is reduced, the controller drives the motor to run slowly, thereby reducing the actual output power of the pump. Compared with the traditional power frequency motor (constant speed), the power consumption of the pump is greatly reduced. This enables users to save power.



TEFC secondary motor

Protection class: IP55

Insulation class: F


Protection class: IP55

Input power: 1×220 V 50/60Hz

Frequency variable range: 30~60Hz




CNP, a green water expert beside you.





Frequency conversion range: 30~60Hz


Filtration water system

Industrial water circulation system

Cooling water system

Urban residential home water supply system
